Ideal Plastic, a leading China supplier of high-performance thermoplastics, offers Bearing Grade PEEK Rods – a carbon-fiber, graphite, and PTFE‑filled compound that delivers ultra‑low friction, exceptional wear resistance, and outstanding thermal stability up to 343°C. With over 14 years of R&D and ISO9001:2008 certification, our rods maintain ±0.02 mm precision, serving aerospace, medical, and industrial sectors worldwide.
Ideal Plastic manufactures Bearing Grade PEEK Rods from a proprietary blend of PEEK, carbon fiber, graphite, and PTFE. This formulation significantly reduces friction and enhances machinability while preserving PEEK's inherent chemical resistance, high‑temperature endurance, and electrical insulation. Ideal for high‑speed, high‑pressure bearing, bushing, and seal applications.
Engineered for durability, these rods offer a balanced profile of mechanical, thermal, and chemical characteristics.
High tensile strength and stiffness resist creep and deformation under continuous load, ensuring reliable performance in thrust washers and rollers.
Unaffected by acids, alkalis, and organic solvents – ideal for pump parts, valve seats, and piping in aggressive chemical environments.
Withstands gamma radiation and repeated steam autoclaving at 260°C with less than 5% property loss after multiple cycles.
Melting point at 343°C; retains >90% of strength after 16 weeks at 250°C – critical for automotive and oil‑gas applications.
Volume resistivity 1016 Ω·cm, dielectric constant 3.2–3.5, and dissipation factor <0.002 – excellent for electronic connectors and insulators.
| Parameter | Details |
|---|---|
| Product Name | Bearing Grade PEEK Rods |
| Material | Pure PEEK + Carbon Fiber + Graphite + PTFE |
| Color | Black |
| Diameter Range | 3 mm – 300 mm |
| Standard Length | 1000 mm or 3000 mm |
| Tolerance | ±0.02 mm |
| Samples | Free (shipping cost applies) |
| Minimum Order Quantity | 1 piece |
| Certifications | ISO9001:2008, REACH, RoHS |
Low friction, wear resistance, and thermal stability make these rods versatile across multiple sectors.
Lightweight and corrosion‑resistant – used in fasteners, connectors, and brackets to reduce weight and improve fuel efficiency.
Surgical instruments and catheter connectors withstand repeated steam sterilization without dimensional change.
Bearings, bushings, gears, and seals operate reliably in high‑load, high‑temperature, chemically aggressive environments.
Excellent dielectric properties and low moisture absorption suit wafer handling, test sockets, and high‑voltage insulators.
Light weight and high strength support portable equipment and vehicle components in extreme conditions.
Robot joints and gears achieve 40% weight reduction vs. metal while maintaining >200 MPa tensile strength, enabling smoother motion and higher payload.
Streamlined procurement for Bearing Grade PEEK Rods – transparent terms and flexible options.
Just 1 piece for profile rods; custom parts negotiable.
Free samples of in‑stock profiles (customer pays shipping). Sample quality matches production orders.
Partial deposit before production, balance upon completion. Pay via HSBC Hong Kong or your freight forwarder.
We ship via DHL, FedEx, or sea freight. Accept customer‑designated logistics. Shipping costs borne by buyer.
For quality defects, we cover return shipping and replacement. For customer‑initiated returns (resalable condition), buyer pays return shipping.
Ideal Plastic operates large‑scale profile production lines, CNC machining centers (including 4‑axis and 5‑axis), engraving machines, laser cutters, and a Class 100,000 dust‑free injection molding workshop. This advanced infrastructure ensures precise, consistent production of Bearing Grade PEEK Rods and custom‑machined parts.
Our quality system is ISO9001:2008 certified. All Bearing Grade PEEK Rods comply with REACH, RoHS, and EN71 standards, with third‑party SGS and CE certifications available upon request. Each batch is accompanied by a material report and undergoes rigorous in‑house testing for mechanical, thermal, and dimensional properties.
We accept 2D/3D drawings (STEP, STP, STL, IGS, PRT, SLDPRT, SAT, X_T) and can reverse‑engineer from samples. Our R&D team of over 100 professionals provides material selection advice, prototype development, and CNC machining services to deliver finished parts to your exact specifications.
Since 2011, Ideal Plastic has been a premier China manufacturer of specialty engineering plastics. With vertical integration, over 14 years of experience, and a 100‑plus R&D team, we ensure consistent quality, competitive lead times, and responsive customer support. We serve clients in Europe, the US, the Middle East, Japan, Korea, and Southeast Asia.
A: Contact us with any issues – our technical team will diagnose and resolve them based on extensive experience with PEEK materials.
A: Partial deposit before production, balance due upon completion. Payment via HSBC Hong Kong or your freight forwarder.
A: ISO9001:2008, REACH, RoHS, EN71, and optional SGS/CE certifications.
A: For quality defects, we cover return shipping and replacement. For customer errors, buyer pays return shipping on resalable items.
A: Yes, free samples of in‑stock profiles – just pay shipping. Sample quality is identical to production.
